Tafels
GRAND TABLE
GRAND TABLE – de tijdloze vergadertafel. Met GRAND TABLE worden er talrijke vormgevingsopties in vergader- en conferentieruimtes aangeboden. De klassieke rechthoekige en ovale tafelvormen zijn in verschillende groottes verkrijgbaar en kunnen naar wens gecombineerd worden. Optioneel zijn er een kabelgeleidingssysteem en Netbox beschikbaar.
Downloads
- GRAND_TABLE_Productinformation
(731 KB) - 4520_200x100_Rechteck.dwg
(361 KB) - 4520_210x100_Tonnenform.dwg
(430 KB) - 4520_240x110_Rechteck.dwg
(362 KB) - 4520_240x110_Tonnenform.dwg
(432 KB) - 4520_300x120_Rechteck.dwg
(362 KB) - 4520_300x120_Tonnenform.dwg
(365 KB) - 4520_360x130_Tonnenform.dwg
(321 KB) - 4520_400x130_Rechteck.dwg
(316 KB) - 4520_400x130_Tonnenform.dwg
(324 KB) - 4520_480x130_Rechteck.dwg
(298 KB) - 4520_480x130_Tonnenform.dwg
(338 KB) - DWG_4520_210x100_Rechteckform.dwg
(361 KB) - DWG_4520_360x130_Rechteckform.dwg
(624 KB) - DWG_4520_360x130_Tonnenform.dwg
(636 KB) - DWG_4520_400x130_Rechteckform.dwg
(626 KB) - DWG_4520_480x130_Rechteckform.dwg
(651 KB)
Frame
4-legged base made of rectangular steel tube, steel legs made of rectangular tube 70 x 30 x 2 mm, screwed to frame. Frame made of rectangular tube 50 x 15 x 2 mm. From a table length of more than 300 cm, frame made of rectangular tube 60 x
20 x 2 mm, with integrated stabilizer function.
6-legged base made of rectangular steel tube, steel legs made of rectangular tube 70 x 30 x 2 mm, screwed to the frame. Frame made of rectangular tube 50 x 15 x 2 mm. Other sizes on demand.
Frame surfaces
4-legged base, steel legs standard chromium-plated or powder-coated black, optionally powder-coated according to BRUNE® collection. Frame standard chromium-plated or powder-coated black, optionally powder-coated according to BRUNE® collection. From a table length of more than 300 cm, frame standard powder-coated black, optionally powder- coated according to BRUNE® collection.
6-legged base, steel legs standard chromium-plated or powder-coated black, optionally powder-coated according to BRUNE® collection. Frame standard chromium-plated or powder-coated black, optionally powder-coated according to BRUNE® collection.
Table tops
Table top C: 30 mm thick, multi-layer particle board, E1, coated in high pressure laminate (HPL) or veneer according to BRUNE® collection. Plate bottom side HPL white or beech veneer. ABS edging in connection with laminated top or veneer edging in combination with veneered table top.
Table top R: 30 mm thick, 28 mm strong multi-layered plywood, surface coated in high-pressure laminate (HPL) or veneer according to BRUNE® collection. Lower surface: HPL white or beech veneer. Edges multi-layered plywood, straight edges, 9 mm thick, beveled over 35 mm.
Table top MDF: 30 mm thick, made from medium-density fiberboard (28 mm), all surfaces lacquered, optionally available in veneer according to BRUNE® collection. MDF edging, with a 9 mm straight edge, beveled over 35 mm. For veneered surfaces: straight edge, veneered, MDF: beveled edge, stained and varnished.
Veneer fisnish
Real wood veneer from the BRUNE® collection comes as a standard varnished with a low solvent content water-based lacquer, optionally stained to the BRUNE® collection.
HPL surfaces
Resopal®-HPL from the BRUNE® collection.
Gliders
Standard plastic gliders.
Dimensions and weight
Table height: |
| 75 cm | ||
Table sizes HPL: | ||||
Width min. Length min. | 80 cm 140 cm | |||
Weight: Table - rectangular | ||||
210 x 100 cm 240 x 110 cm 300 x 120 cm 360 x 130 cm 400 x 130 cm 480 x 130 cm | 63 kg 75 kg 96 kg 132 kg 140 kg 169 kg | |||
Weight: Table - boat-shaped | ||||
210 x 100 cm 240 x 110 cm 300 x 120 cm 360 x 130 cm 400 x 130 cm 480 x 130 cm | 60 kg 71 kg 90 kg 118 kg 136 kg 164 kg |
Eduard Euwens
Eduard Euwens (geb. in 1970) volgde een opleiding tot meubelmaker, voordat hij in Münster voor een designopleiding koos. In 2000 sloot hij zijn opleiding af als Diplom-Designer en vergaarde hierna ervaring als ontwerper voor diverse ontwerpbureaus. Sinds 2004 ontwerpt hij met zijn eigen studio producten voor alledaags gebruik. Zijn ontwerpen voor BRUNE werden door de "Rat für Formgebung" ofwel German Design Council reeds als bijzonder beoordeeld.
Eduard Euwens woont en werkt in Münster.
